دستهبندی: لوازم و تجهیزات جوش برش
SUPPLY VOLTAGE (VAC): AC 380V ± 15%
INPUT FREQUENCY (HZ): 50
RATED INPUT CURRENT (A): 19.5 @ TIG 21.0 @ MMA
OUTPUT CURRENT ADJUSTMENT RANGE (TIG) (A): 6 ~ 315
در حال بارگزاری...
برگشت به بالا
SUPPLY VOLTAGE (VAC)
AC 380V ± 15%
INPUT FREQUENCY (HZ)
50
RATED INPUT CURRENT (A)
19.5 @ TIG 21.0 @ MMA
OUTPUT CURRENT ADJUSTMENT RANGE (TIG) (A)
6 ~ 315
OUTPUT CURRENT ADJUSTMENT RANGE (MMA) (A)
10 ~ 270
ARC FORCE CURRENT ADJUSTMENT RANGE (A)
0 ~ 100
POWER CAPACITY (KVA)
9 @ TIG 10.0 @ MMA
HOT START CURRENT ADJUSTMENT RANGE (A)
0 ~ 80
OPEN CIRCUIT VOLTAGE (V)
12.5
RATED OPERATING VOLTAGE (V)
22.6 @ TIG 30.8@MMA
BASE CURRENT (A)
6 ~ 315
AC OUTPUT FREQUENCY (HZ)
50 ~ 200
PULSE FREQUENCY AC (HZ)
0.5 ~ 20
BALANCE (%)
20 ~ 60
POST FLOW TIME (S)
0.5 ~ 15
PULSE DUTY CYCLE (%)
5 ~ 95
UPSLOPE TIME (S)
0 ~ 15
HOT START CURRENT TIME (S)
0.01 ~ 15
REMOTE CONTROL
YES
DOWNSLOPE TIME (S)
0 ~ 15
PRE FLOW TIME (S)
0.5 ~ 10
PULSE FREQUENCY DC (HZ)
0.5 ~ 200
ARC IGNITION MODE
HF Ignition
ACDC MIXED DUTY CYCLE (DC)
5.0 ~ 95
ACDC MIXED OUTPUT FREQUENCY (HZ)
1.0 ~ 20
POWER FACTOR
0.7
INSULATION CLASS
F
DUTY CYCLE (%)
TIG 315 30% - MMA:270 @ 30%
PROTECTION CLASS
IP21S
DIMENSION(L*W*H)
522*267*442
EFFICIENCY
80
Weight
26
